型號： ES52C1A10V-32.000MTR
廠商： ECLIPTEK CORP
元件分類： XO, clock
英文描述： TCVCXO, CLIPPED SINE OUTPUT, 32 MHz
封裝： ROHS COMPLIANT, CERAMIC, SMD, 10 PIN
文件頁數： 1/5頁
文件大?。?/td> 158K
代理商： ES52C1A10V-32.000MTR
Pb
RoHS
ES52C1A10V-32.000M TR
ES52C1 A 10 V -32.000M TR
Series
RoHS Compliant (Pb-free) 5mm x 7mm Ceramic SMD
3.3Vdc Clipped Sinewave TC(VC)XO
Operating Temperature Range
0°C to +50°C
Frequency Stability
±1.0ppm Maximum
Packaging Options
Tape & Reel
Nominal Frequency
32.000MHz
Control Voltage
1.5Vdc ±1.0Vdc
ELECTRICAL SPECIFICATIONS
Nominal Frequency
32.000MHz
Frequency Stability vs. Frequency
Tolerance
±1.0ppm Maximum (Measured at 25°C ±2°C, Vdd=3.3Vdc, Vc=1.5Vdc)
Frequency Stability
±1.0ppm Maximum
Frequency Stability vs. Input Voltage
±0.2ppm Maximum (Vdd ±5%)
Frequency Stability vs. Aging
±1ppm/Year Maximum (at 25°C)
Frequency Stability vs. Load
±0.2ppm Maximum (±1kOhm//±1pF)
Operating Temperature Range
0°C to +50°C
Supply Voltage
3.3Vdc ±5%
Input Current
2.5mA Maximum
Output Voltage
0.8Vp-p Clipped Sinewave Minimum
Load Drive Capability
10kOhms//10pF
Output Logic Type
Clipped Sinewave
Control Voltage
1.5Vdc ±1.0Vdc
Frequency Deviation
±8ppm Minimum
Linearity
10% Maximum
Transfer Function
Positive Transfer Characteristic
Modulation Bandwidth
3kHz Minimum (Measured at -3dB with a Control Voltage of 1.5Vdc)
Input Impedance
100kOhms Minimum
Phase Noise
-80dBc/Hz at 10Hz offset, -115dBc/Hz at 100Hz offset, -135dBc/Hz at 1kHz offset, -145dBc/Hz at 10kHz
offset, -145dBc/Hz at 100kHz offset (Typical Values, at 12.800MHz)
Start Up Time
5mSec Maximum
Storage Temperature Range
-55°C to +125°C
ENVIRONMENTAL & MECHANICAL SPECIFICATIONS
Fine Leak Test
MIL-STD-883, Method 1014 Condition A
Gross Leak Test
MIL-STD-883, Method 1014 Condition C
Mechanical Shock
MIL-STD-202, Method 213 Condition C
Resistance to Soldering Heat
MIL-STD-202, Method 210
Resistance to Solvents
MIL-STD-202, Method 215
Solderability
MIL-STD-883, Method 2003
Temperature Cycling
MIL-STD-883, Method 1010
Vibration
MIL-STD-883, Method 2007 Condition A
www.ecliptek.com | Specification Subject to Change Without Notice | Rev J 3/13/2011 | Page 1 of 5
