RPM-Based Fan Controller with HW Thermal Shutdown
Datasheet
Revision 0.90 (08-19-08)
44
SMSC EMC2103
DATASHEET
During Power-On-Reset (POR), the default values are stored in the registers. A POR is initiated when
power is first applied to the part and the voltage on the VDD supply surpasses the POR level as
specified in the electrical characteristics. Any reads to undefined registers will return 00h. Writes to
undefined registers will not have an effect.
6.1.1
Lock Entries
The Lock Column describes the locking mechanism, if any, used for individual registers. All SWL
registers are Software Locked and therefore made read-only when the LOCK bit is set.
78h
R/W
LUT Temp 4
Setting 8
Stores the threshold level for the
Internal Diode channel (or Pushed
Temp 2 temp) that is associated with
the Drive 8 value
7Fh
(127°C)
LUT
Lock
79h
R/W
LUT Temp
Hysteresis
Stores the hysteresis that is shared
for all temperature inputs
0Ah
(10°C)
LUT
Lock
E1h **
R/W
GPIO Direction
Register **
Controls the GPIO direction for
GPIOs 1 and 2
00h
No
E2h **
R/W
GPIO Output
Configuration
Register **
Controls the output type of GPIOs 1
and 2
00h
No
E3h **
R/W
GPIO Input
Register **
Stores the inputs for GPIOs 1 and 2
00h
No
E4h **
R/W
GPIO Output
Register **
Controls the output state of GPIOs 1
and 2
00h
No
E5h **
R/W
GPIO Interrupt
Enable Register **
Enables interrupts for GPIOs 1 and 2
00h
No
E6h **
R/W
GPIO Status **
Indicates when the GPIOs change
state
00h
No
Lock Register
EF
R/W
Software Lock
Locks all SWL registers
00h
SWL
Revision Registers
FCh
R
Product Features
Indicates which pin selected options
are enabled
00h
No
FDh
R
Product ID
EMC2103-1
Stores the unique Product ID
24h
No
Product ID
EMC2103-2
26h
No
FEh
R
Manufacturer ID
5Dh
No
FFh
R
Revision
00h
No
Table 6.1 EMC2103 Register Set (continued)
ADDR
R/W
REGISTER
NAME
FUNCTION
DEFAULT
VALUE
LOCK
PAGE
