Preliminary
...the world's most energy friendly microcontrollers
2013-06-28 - EFM32GG980FXX - d0045_Rev1.10
54
www.energymicro.com
Alternate
LOCATION
Functionality
0
1
2
3
4
5
6
Description
I2C0_SCL
PA1
PD7
PC7
PC1
PF1
PE13
I2C0 Serial Clock Line input / output.
I2C0_SDA
PA0
PD6
PC6
PC0
PF0
PE12
I2C0 Serial Data input / output.
I2C1_SCL
PC5
PB12
PE1
I2C1 Serial Clock Line input / output.
I2C1_SDA
PC4
PB11
PE0
I2C1 Serial Data input / output.
LCD_BCAP_N
PA13
LCD voltage booster (optional), boost capacitor, negative
pin. If using the LCD voltage booster, connect a 22 nF ca-
pacitor between LCD_BCAP_N and LCD_BCAP_P.
LCD_BCAP_P
PA12
LCD voltage booster (optional), boost capacitor, positive
pin. If using the LCD voltage booster, connect a 22 nF ca-
pacitor between LCD_BCAP_N and LCD_BCAP_P.
LCD_BEXT
PA14
LCD voltage booster (optional), boost output. If using the
LCD voltage booster, connect a 1 uF capacitor between
this pin and VSS.
An external LCD voltage may also be applied to this pin if
the booster is not enabled.
If AVDD is used directly as the LCD supply voltage, this
pin may be left unconnected or used as a GPIO.
LCD_COM0
PE4
LCD driver common line number 0.
LCD_COM1
PE5
LCD driver common line number 1.
LCD_COM2
PE6
LCD driver common line number 2.
LCD_COM3
PE7
LCD driver common line number 3.
LCD_SEG0
PF2
LCD segment line 0. Segments 0, 1, 2 and 3 are con-
trolled by SEGEN0.
LCD_SEG3
PF5
LCD segment line 3. Segments 0, 1, 2 and 3 are con-
trolled by SEGEN0.
LCD_SEG4
PE8
LCD segment line 4. Segments 4, 5, 6 and 7 are con-
trolled by SEGEN1.
LCD_SEG5
PE9
LCD segment line 5. Segments 4, 5, 6 and 7 are con-
trolled by SEGEN1.
LCD_SEG6
PE10
LCD segment line 6. Segments 4, 5, 6 and 7 are con-
trolled by SEGEN1.
LCD_SEG7
PE11
LCD segment line 7. Segments 4, 5, 6 and 7 are con-
trolled by SEGEN1.
LCD_SEG8
PE12
LCD segment line 8. Segments 8, 9, 10 and 11 are con-
trolled by SEGEN2.
LCD_SEG9
PE13
LCD segment line 9. Segments 8, 9, 10 and 11 are con-
trolled by SEGEN2.
LCD_SEG10
PE14
LCD segment line 10. Segments 8, 9, 10 and 11 are con-
trolled by SEGEN2.
LCD_SEG11
PE15
LCD segment line 11. Segments 8, 9, 10 and 11 are con-
trolled by SEGEN2.
LCD_SEG12
PA15
LCD segment line 12. Segments 12, 13, 14 and 15 are
controlled by SEGEN3.
LCD_SEG13
PA0
LCD segment line 13. Segments 12, 13, 14 and 15 are
controlled by SEGEN3.
LCD_SEG14
PA1
LCD segment line 14. Segments 12, 13, 14 and 15 are
controlled by SEGEN3.
LCD_SEG15
PA2
LCD segment line 15. Segments 12, 13, 14 and 15 are
controlled by SEGEN3.
LCD_SEG16
PA3
LCD segment line 16. Segments 16, 17, 18 and 19 are
controlled by SEGEN4.
LCD_SEG17
PA4
LCD segment line 17. Segments 16, 17, 18 and 19 are
controlled by SEGEN4.
