參數資料
型號： DS1626S+T&R
廠商： MAXIM INTEGRATED PRODUCTS INC
元件分類： Switch/Digital Output Temperature Sensor
英文描述： DIGITAL TEMP SENSOR-SERIAL, 12BIT(s), 0.50Cel, RECTANGULAR, SURFACE MOUNT
封裝： LEAD FREE, SOIC-8
文件頁數： 10/16頁
文件大小： 217K
代理商： DS1626S+T&R
DS1626/DS1726
3 of 14
ABSOLUTE MAXIMUM RATINGS*
Voltage on Any Pin Relative to Ground
-0.5V to +6.0V
Operating Temperature Range
-55°C to +125°C
Storage Temperature Range
-55°C to +125°C
Solder Dip Temperature (10s)
+260°C
Reflow Oven Temperature
+220°C
* These are stress ratings only and functional operation of the device at these or any other conditions
above those indicated in the operation sections of this specification is not implied. Exposure to absolute
maximum rating conditions for extended periods of time may affect reliability.
DC ELECTRICAL CHARACTERISTICS
(VDD = 2.7V to 5.5V; TA = -55°C to +125°C.)
PARAMETER
SYMBOL
CONDITIONS
MIN
TYP
MAX
UNITS
Supply Voltage
VDD
(Note 1)
2.7
5.5
V
0°C to +70°C,
3.0V
≤ V
DD ≤ 5.5V
±0.5
0°C to +70°C,
2.7V
≤ V
DD < 3.0V
±1.25
DS1626
Thermometer Error
(Note 2)
TERR
-55°C to +125°C
±2
°C
-10°C to +85°C,
3.0V
≤ V
DD ≤ 5.5V
±1
-10°C to +85°C,
2.7V
≤ V
DD < 3.0V
±1.5
DS1726
Thermometer Error
(Note 2)
TERR
-55°C to +125°C
±2
°C
Low-Level Input
Voltage
VIL
(Note 1)
-0.5
0.3 x VDD
V
High-Level Input
Voltage
VIH
(Note 1)
0.7 x VDD
VDD + 0.3
V
Input Current each
Input Pin
0.4 < VI/O < 0.9 x VDD
-10
+10
A
Temperature conversion
-55°C to +85°C
1
Temperature conversion
+85°C to +125°C
1.25
mA
Active Supply
Current (Note 3)
IDD
E
2 write
400
A
Input Resistance
RI
RST
to GND
DQ, CLK to VDD
1
M
Ω
Standby Supply
Current
ISTBY
0°C to +70°C (Note 3)
1.5
A
THIGH, TLOW,
VOH
1mA source current
2.4
V
