DS1556
17 of 21
AC TEST CONDITIONS
Output Load:
100 pF + 1TTL Gate
Input Pulse Levels:
0.0 to 3.0 Volts
Timing Measurement Reference Levels:
Input: 1.5V
Output: 1.5V
Input Pulse Rise and Fall Times: 5 ns
NOTES:
1. Voltage referenced to ground.
2. Typical values are at 25
°C and nominal supplies.
3. Outputs are open.
4. Battery switch over occurs at the lower of either the battery voltage or VPF.
5. The IRQ /FT and RST outputs are open drain.
6. Data retention time is at 25
°C.
7. Each DS1556 has a built-in switch that disconnects the lithium source until VCC is first applied by the
user. The expected tDR is defined for DIP modules and PowerCap modules as a cumulative time in
the absence of VCC starting from the time power is first applied by the user.
8. Real Time Clock Modules (DIP) can be successfully processed through conventional wave-soldering
techniques as long as temperature exposure to the lithium energy source contained within does not
exceed +85
°C. Post solder cleaning with water washing techniques is acceptable, provided that
ultrasonic vibration is not used.
In addition, for the PowerCap:
a. Dallas Semiconductor recommends that PowerCap Module bases experience one pass through
solder reflow oriented with the label side up (“l(fā)ive-bug”).
b. Hand soldering and touch-up: Do not touch or apply the soldering iron to leads for more than 3
seconds. To solder, apply flux to the pad, heat the lead frame pad and apply solder. To remove
the part, apply flux, heat the lead frame pad until the solder reflow and use a solder wick to
remove solder.
9. tAH1, tDH1 are measured from WE going high.
10. tAH1, tDH1 are measured from CE going high.
