DC/DC Converters
ctparts.com
Manufacturer of Passive and Discrete Semiconductor Components
800-684-5322 Inside US
949-453-1811 Outside US
Copyright 2006 by CT Magnetics, DBA Central Technologies. All rights reserved.
CT Magnetics reserves the right to make improvements or change specifications without notice
CENTRAL Technologies
OUTLINE DIMENSIONS & RECOMMENDED FOOTPRINT DETAILS
50.8
10.20
4.10
20.3
2
1
3
5
5.08
25.4
20.3
1.60+0.15/-0
2.54
Note: All Pins on a 2.54m pitch; all pin diameters are 0.50mm; all dimensions in mm.
CTDD5025DF-S1K-10M Package
CTDD5025DF-S1K-10M Footprint
PIN CONNECTIONS
Bottom View
Pin
1
2
3
5
Function
GND
Vin
+Vo
0V
2
1
3
5
12.18.06
CTDD5025DF-S1K-10M Series
Wide Input Isolated & Regulated
10W Output, Single Output
Vin
Cin
12V
24V
100F
each 1A
Current
100F
External Capacitor Table (table 1)
All the CTDD5025DF-S1K-10M Series have been tested according to the following recommended testing circuit before
leaving factory. This series should be tested under load. Never be tested under no load (See figure 1). When it is used in
unregulated power supply, be sure that the flucuating range of the power supply adn the rippled voltage do not exceed the
module standard. Input current of power supply should afford the startup current of this kind of DC/DC module. (See figure 2)
Input Voltage
Range
lp
Input
C
urr
ent
(A)
Input Voltage (V)
++
DC
Vin
GND
Cin
Vout
0V
Cout
Figure 1
Figure 2
Vout
Cout
48V
5V
12V
24V
15V
RECOMMENDED CIRCUIT
