參數資料
| 型號： | BUF634PG4 |
| 英文描述： | 250mA HIGH-SPEED BUFFER |
| 中文描述： | 250mA的高速緩沖 |
| 文件頁數： | 3/12頁 |
| 文件大?。?/td> | 256K |
| 代理商： | BUF634PG4 |
BUF634
3
PIN CONFIGURATION
Top View
8-Pin Dip Package
SO-8 Surface-Mount Package
Top View
Supply Voltage .....................................................................................
±
18V
Input Voltage Range ...............................................................................
±
V
S
Output Short-Circuit (to ground) .................................................Continuous
Operating Temperature ..................................................... –40
°
C to +125
°
C
Storage Temperature ........................................................ –55
°
C to +125
°
C
Junction Temperature .......................................................................+150
°
C
Lead Temperature (soldering,10s)....................................................+300
°
C
NC = No Connection
BW
NC
V
IN
V–
NC
V+
V
O
NC
1
2
3
4
8
7
6
5
G = 1
Any integrated circuit can be damaged by ESD. Burr-Brown
recommends that all integrated circuits be handled with
appropriate precautions. Failure to observe proper handling
and installation procedures can cause damage.
ESD damage can range from subtle performance degrada-
tion to complete device failure. Precision integrated circuits
may be more susceptible to damage because very small
parametric changes could cause the device not to meet
published specifications.
ELECTROSTATIC
DISCHARGE SENSITIVITY
NOTE: Tab electrically
connected to V–.
G = 1
G = 1
V–
V
O
V+
V
IN
BW
1 2 3 4 5
5-Lead
TO-220
V–
V
O
V+
V
IN
BW
1 2 3 4 5
5-Lead DDPAK
Surface Mount
PACKAGE
DRAWING
NUMBER
(1)
TEMPERATURE
RANGE
PRODUCT
PACKAGE
BUF634P
BUF634U
BUF634T
BUF634F
8-Pin Plastic DIP
SO-8 Surface-Mount
5-Lead TO-220
5-Lead DDPAK
006
182
315
325
–40
°
C to +85
°
C
–40
°
C to +85
°
C
–40
°
C to +85
°
C
–40
°
C to +85
°
C
NOTE: (1) For detailed drawing and dimension table, please see end of data
sheet, or Appendix C of Burr-Brown IC Data Book.
PACKAGE/ORDERING INFORMATION
ABSOLUTE MAXIMUM RATINGS
