參數資料
| 型號： | AWL6153M7UP8 |
| 廠商： | ANADIGICS INC |
| 元件分類： | 放大器 |
| 英文描述： | 2400 MHz - 2485 MHz RF/MICROWAVE NARROW BAND MEDIUM POWER AMPLIFIER |
| 封裝： | 4 X 4 MM, 1.40 MM HEIGHT, ROHS COMPLIANT, M7, 10 PIN |
| 文件頁數： | 2/12頁 |
| 文件大?。?/td> | 346K |
| 代理商： | AWL6153M7UP8 |
10
Data Sheet - Rev 2.1
10/2009
AWL6153
APPLICATION INFORMATION
The only external components required for the
AWL6153 are bypass capacitors for the supply (see
Figure 11: Application Circuit
Figure 11). When VREF is pulled down to 0 V, the
amplifier is placed in a low-current shut down mode.
GND
at slug
RF IN
2
1
6
7
10
8
5
4
3
VCC
N/C
GND
RFIN
GND
VCC
GND
VREF
GND
RFOUT
22uF tantalum
(optional)
VCC1
VREF
RF OUT
0.01uF
x
9
