HIGH POWER CHIP, ALUMINUM NITRIDE
RESISTORS, TERMINATIONS
SERIES ANC
50 & 100 OHMS
GENERAL INFORMATION
When mounted on an appropriate heat sink, these chip devices provide
high power dissipation in terminations and as balancing resistors in
Wilkinson power divider networks. Laser trimming provides maximum peak
and average R.F. power capability. Aluminum nitride is used for those
applications where the use and disposal of beryllium oxide is a concern.
GENERAL SPECIFICATIONS
Resistive Tolerance:
2%
Solderable Terminals:
Electroplated Silver over Nickel
Substrate :
Aluminum Nitride
Resistive Element:
Thin Film
Resistor
Termination
W
L
T
A
B
CAP(pF)
VSWR
Power
FREQ.
Model Prefix
in
[mm]
in
[mm]
in
[mm]
in
[mm]
in
[mm]
Typical
CW
Peak
GHz
ANC 50-50
0.050 [1,3]
0.010 [.254]
N/A
0.010 [.254]
0.5
1.25
5
0.10KW
DC-4.0
ANC 50-100
0.050 [1,3]
0.100 [2,5]
0.010 [.254]
N/A
0.020 [.508]
1.0
1.25
10
0.25KW
DC-2.0
ANC 100-200
0.100 [2,5]
0.200 [5,1]
0.040 [1,0]
N/A
0.030 [.762]
1.0
1.25
10
1KW
DC-4.0
ANC 200-200
0.200 [5,1]
0.040 [1,0]
0.085 [2,2]
0.040 [1,0]
1.2
1.25
30
1KW
DC-4.0
ANC 250-250-40
0.250 [6,4]
0.040 [1,0]
0.085 [2,2]
0.050 [1,3]
1.0
1.15
40
2KW
DC-2.5
ANC 250-250-80
0.250 [6,4]
0.040 [1,0]
N/A
0.050 [1,3]
1.6
1.25
80
4KW
DC-1.0
ANC 250-375
0.250 [6,4]
0.375 [9,5]
0.040 [1,0]
N/A
0.050 [1,3]
4.5
1.25
125
4KW
DC-1.0
ANC 350-225
0.350 [8,9]
0.225 [5,7]
0.040 [1,0]
0.02 [.508]
0.050 [1,3]
1.4
1.25
100
2KW
DC-2.0
ANC 375-375
0.375 [9,5]
0.040 [1,0]
0.25 [6,4]
0.050 [1,3]
4.5
1.25
200
4KW
DC-1.0
PERFORMANCE SPECIFICATIONS
Notes:
1. The “L” and “T” dimensions are for the substrate only and do not
include terminal thickness or optional tinning thickness.
2. The CW power rating is based on maximum film temperature of
+150°C and with maximum heatsink temperature of +100°C. Power is
based on infinite and ideal heatsink.
TYPICAL MODEL NO.
NPC
T
250-250
X
50
Prefix
Tinning
(if required)
Size
Terminal type (X, G)
Ohmic Value (*)
50
or
100
TYPICAL MODEL NO.
ANC
X
TOP
VIEW
W
B
T
L
B
TYPE X
(RESISTOR)
T
L
B
TYPE G
(TERMINATION)
50 Ohms
or
100 Ohms
50 Ohms
ONLY
0.005
[0,13]
MAX
A
(FULL FILM)
(NARROW FILM)
KEY: Inches[Millimeters] .XX ±.03 .XXX ±.010 [.X ±0.8 .XX ±0.25]
60 South Jefferson Road, Whippany, NJ 07981 s Tel: 973-887-8100 s Fax: 973-884-0445
E-Mail: sales@mcekdi-resistor.com s See us on the web @ www.mcekdi-resistor.com
8/02
