型號： ALM-1712-TR1G
元件分類： 放大器
英文描述： RF/MICROWAVE NARROW BAND LOW POWER AMPLIFIER
封裝： 4.50 X 2.20 MM, 1 MM HEIGHT, HALOGEN FREE AND LEAD FREE, MCOB, 12 PIN
文件頁數： 6/18頁
文件大小： 325K
代理商： ALM-1712-TR1G
14
ALM-1712 Typical Scattering Parameters at 25
qC, Vdd = 1.8V, Idd = 4mA
Freq
S11
S21
S12
S22
(GHz)
Mag.
Ang.
Mag.
Ang.
Mag.
Ang.
Mag.
Ang.
0.05
-11.7162
-170.7106
-81.6489
-23.9651
-79.9989
166.0013
-0.0126
-6.4575
0.1
-7.7018
-171.4037
-90.7921
41.4586
-89.7263
12.5338
-0.0118
-12.8900
0.2
-4.2936
160.2101
-87.5836
129.6997
-82.2771
4.1346
-0.0230
-25.7784
0.3
-2.6502
128.1445
-87.6370
69.2383
-84.0300
156.2300
-0.0388
-38.6553
0.4
-1.6292
97.8663
-84.9802
68.7977
-92.0657
120.1065
-0.0585
-51.7725
0.5
-1.1819
71.0839
-89.4916
91.3343
-83.3124
74.6750
-0.0829
-64.6993
0.6
-0.9370
47.0797
-83.7495
34.3433
-88.9090
55.9706
-0.1161
-77.6595
0.7
-0.7687
24.9542
-91.9936
32.7459
-84.5974
61.4150
-0.1561
-90.6813
0.8
-0.6818
4.2036
-88.8808
13.4125
-82.3807
61.8048
-0.1997
-103.7763
0.8275
-0.6681
-1.4945
-87.1387
30.0060
-85.8761
56.5107
-0.2133
-107.4801
0.9
-0.6419
-15.6543
-87.4630
20.0434
-80.3162
35.6866
-0.2493
-116.9728
1.0
-0.6391
-35.3217
-87.3744
0.7020
-86.5401
34.8313
-0.3091
-130.4893
1.1
-0.6706
-54.4991
-88.9095
31.5028
-81.4517
24.3737
-0.3754
-144.0612
1.2
-0.7317
-73.9540
-83.6750
4.8216
-97.0178
-9.7918
-0.4438
-157.9779
1.3
-0.8422
-94.3547
-82.8541
2.5784
-87.6032
45.8691
-0.5225
-172.6498
1.4
-1.0218
-117.7708
-81.3320
19.6979
-82.0519
38.3422
-0.6345
170.6171
1.5
-3.1178
-158.6405
-66.2178
0.2042
-75.6859
17.9411
-1.8370
143.6288
1.575
-14.6222
102.7963
11.1602
46.9620
-19.8837
-24.0104
-6.5680
-93.3582
1.6
-1.2793
-90.3379
-5.8793
165.1758
-36.3706
93.3756
-2.9708
-132.5178
1.7
-1.0178
-148.2247
-83.8168
-43.9663
-82.2421
-36.3426
-0.6790
152.7334
1.8
-1.1860
-174.0191
-75.9294
-18.0396
-85.5619
4.6318
-0.7492
133.6285
1.885
-1.3016
166.8680
-70.1464
-29.1946
-81.8251
-8.5338
-0.8019
120.3211
1.9
-1.3205
163.4637
-70.5762
-38.8621
-81.5867
17.4759
-0.8092
117.9725
2.0
-1.4019
141.6880
-63.2144
-73.4820
-75.6511
33.8800
-0.8490
103.1937
2.1
-1.4597
119.9921
-59.1414
-118.9450
-74.2689
17.1435
-0.8795
88.6655
2.2
-1.4900
98.3343
-56.7200
-167.3326
-70.3523
8.8174
-0.9004
74.3125
2.3
-1.4861
76.1362
-56.0579
144.3719
-67.5578
-0.0975
-0.9188
59.7354
2.4
-1.4760
53.9349
-56.2543
101.6464
-65.8084
-23.7959
-0.9264
45.4328
2.5
-1.4724
31.2536
-57.0216
67.1937
-64.7406
-40.7992
-0.9254
31.1044
3.0
-2.4114
-100.7647
-63.8220
-105.0724
-63.6113
-140.8477
-0.8813
-40.5859
3.5
-3.3164
60.2853
-55.5163
156.2360
-64.0937
-112.6474
-0.8934
-113.2368
4.0
-2.0182
-81.3162
-32.5908
-13.8150
-55.4589
-86.6975
-4.3320
153.6624
4.5
-2.0857
-175.5834
-31.5732
161.9374
-43.8706
118.0248
-3.9425
155.8739
5.0
-2.0953
103.1925
-35.7693
60.2045
-43.4300
32.4125
-3.3736
76.4837
6.0
-1.9438
-20.2189
-39.8779
82.5946
-43.4078
-98.0588
-5.5361
-59.2868
7.0
-3.2605
168.5654
-19.7146
-135.9872
-38.5736
-152.9212
-19.3950
-47.0087
8.0
-3.1021
-14.6426
-19.9574
76.9500
-34.7821
72.9994
-3.7442
98.7381
9.0
-5.6083
159.6227
-11.4095
-135.0280
-22.3814
-125.4177
-4.2361
-13.1301
10.0
-4.7026
-11.4639
-19.0763
56.3564
-26.1326
44.5143
-1.9891
-140.5650
11.0
-6.2228
-177.4774
-17.0007
-37.7901
-41.0067
156.6205
-3.1124
75.5748
12.0
-6.8973
-3.4399
-14.8051
170.6036
-26.5812
-137.3411
-4.9162
-50.7293
13.0
-7.8639
-173.4644
-7.9918
-9.5177
-16.9112
30.0451
-7.5108
172.8073
14.0
-5.3591
18.5501
-10.5670
151.8408
-17.3432
-170.1950
-6.7888
82.0130
15.0
-2.6722
-148.4887
-19.7885
-21.5803
-24.1183
19.1445
-6.8135
-76.3488
16.0
-2.7273
66.4705
-28.4288
-71.7468
-30.7434
-72.7299
-5.3249
97.7321
17.0
-3.1547
-75.2469
-21.7596
159.6029
-26.4143
-177.2816
-4.0002
-51.4573
18.0
-4.8167
139.8221
-17.5940
5.2128
-20.4594
32.8663
-4.4196
161.0736
19.0
-6.4763
38.1618
-18.1592
-142.5790
-20.5410
-115.4139
-6.1810
10.7320
20.0
-4.0478
-82.6401
-18.1698
9.8842
-19.4516
35.7041
-3.8017
-49.8195
