| 型號： | ABM8G-16.000MHZ-18-R80-D-2-Y-T |
| 廠商： | ABRACON CORP |
| 元件分類： | 晶體 |
| 英文描述： | QUARTZ CRYSTAL RESONATOR, 16 MHz |
| 封裝： | ROHS COMPLIANT, ULTRA MINIATURE, CERAMIC, SMD, 4 PIN |
| 文件頁數： | 2/2頁 |
| 文件大小： | 1126K |
| 代理商： | ABM8G-16.000MHZ-18-R80-D-2-Y-T |
|||||||||||||| |
ABM8G
Pb RoHS
Compliant
ABRACON IS
ISO 9001 / QS 9000
CERTIFIED
ABRACON IS
ISO 9001 / QS 9000
CERTIFIED
30332 Esperanza, Rancho Santa Margarita, California 92688
tel 949-546-8000 | fax 949-546-8001| www.abracon.com
3.2 x 2.5 x 1.0mm
Revised: 12.22.09
Visit www.abracon.com for Terms & Conditions of Sale
Dimensions: Inch (mm)
Dimensions: mm
OUTLINE DRAWING:
TAPE & REEL: (1000pcs/reel or 3000pcs/reel)
Note: Due to the availability of raw materials,
this part may be manufactured with the
chamfer on pin 4. Be advised that this does
not affect the electrical characteristics of
the crystal in any way.
Need a test socket for the ABM8G Series? To view
compatible PRECISION TEST & BURN-IN SOCKETS
for these parts, click here.
REFLOW PROFILE:
Tape and reel (1,000pcs/reel)
: Tape and reel (3,000pcs/reel)
ULTRA MINIATURE CERAMIC GLASS SEALED SMD CRYSTAL
ATTENTION: Abracon Corporation’s products are COTS – Commercial-Off-The-Shelf products; suitable for
Commercial, Industrial and, where designated, Automotive Applications. Abracon’s products are not
specifically designed for Military, Aviation, Aerospace, Life-dependant Medical applications or any applica-
tion requiring high reliability where component failure could result in loss of life and/or property. For
applications requiring high reliability and/or presenting an extreme operating environment, written
consent and authorization from Abracon Corporation Is required. Please contact Abracon Corporation for
more information.
