SN54LVTH18512, SN54LVTH182512, SN74LVTH18512, SN74LVTH182512
3.3-V ABT SCAN TEST DEVICES
WITH 18-BIT UNIVERSAL BUS TRANSCEIVERS
SCBS671B – AUGUST 1996 – REVISED OCTOBER 1997
11
POST OFFICE BOX 655303
DALLAS, TEXAS 75265
device-identification register
The device-identification register (IDR) is 32 bits long. It can be selected and read to identify the manufacturer,
part number, and version of this device.
For the ’LVTH18512, the binary value 00000000000000111011000000101111 (0003B02F, hex) is captured
(during Capture-DR state) in the IDR to identify this device as Texas Instruments SN54/74LVTH18512.
For the ’LVTH182512, the binary value 00000000000000111100000000101111 (0003C02F, hex) is captured
(during Capture-DR state) in the device-identification register to identify this device as Texas Instruments
SN54/74LVTH182512.
The IDR order of scan is from TDI through bits 31–0 to TDO. Table 2 shows the IDR bits and their significance.
Table 2. Device-Identification Register Configuration
IDR BIT
NUMBER
IDENTIFICATION
SIGNIFICANCE
IDR BIT
NUMBER
IDENTIFICATION
SIGNIFICANCE
IDR BIT
NUMBER
IDENTIFICATION
SIGNIFICANCE
31
VERSION3
27
PARTNUMBER15
11
MANUFACTURER10
30
VERSION2
26
PARTNUMBER14
10
MANUFACTURER09
29
VERSION1
25
PARTNUMBER13
9
MANUFACTURER08
28
VERSION0
24
PARTNUMBER12
8
MANUFACTURER07
––
23
PARTNUMBER11
7
MANUFACTURER06
––
22
PARTNUMBER10
6
MANUFACTURER05
––
21
PARTNUMBER09
5
MANUFACTURER04
––
20
PARTNUMBER08
4
MANUFACTURER03
––
19
PARTNUMBER07
3
MANUFACTURER02
––
18
PARTNUMBER06
2
MANUFACTURER01
––
17
PARTNUMBER05
1
MANUFACTURER00
––
16
PARTNUMBER04
0
LOGIC1
––
15
PARTNUMBER03
––
14
PARTNUMBER02
––
13
PARTNUMBER01
––
12
PARTNUMBER00
––
Note that for TI products, bits 11–0 of the device-identification register always contain the binary value 000000101111
(02F, hex).
