Product Brief
71M6513
71M6513H
TDK Semiconductor
’
s Power Meter ICs
Applications
Industrial Meters
Commercial Meters
Residential Meters
The TDK 71M6513 is a highly integrated SOC with an MCU core, RTC, FLASH and LCD driver.
TDK's Single Converter Technology
with a 21bit 2nd order delta-sigma ADC, 6 analog inputs,
digital temperature compensation, precision voltage reference and 32 bit computation engine
supports a wide range of polyphase metering applications with very few low cost external com-
ponents. A 32kHz crystal timebase for the entire system and internal battery backup support for
RAM and RTC further reduce system cost.
Maximum design flexibility is supported with multiple UARTs, I
2
C, power fail comparator,
5V LCD charge pump, up to 22 DIO pins and in-system programmable FLASH which can be
updated with data or application code in operation. Easy conversion to ROM offers unprec-
edented cost structure for high volume applications. The device is offered in high (0.1%) and
low (0.5%) accuracy versions for multifunction residential/commercial meter applications
requiring multiple voltage/current inputs, larger LCD or DIO features.
A complete array of ICE and development tools, programming libraries and reference designs
enable rapid development and certification of meters that meet most demanding worldwide
electricity metering standards.
Features
< 0.1% WH accuracy over 2000:1 range (71M6513H version)
Exceeds IEC61036 / IEC62053 / ANSIC12.20
Voltage reference < 10ppm/°C spec (71M6513H version)
Six sensor inputs-VDD referenced
Four quadrant metering
Voltage angles-phase sequence
Digital temperature compensation
21bit 2nd-order delta-sigma ADC
Independent 32bit compute engine
Low jitter pulse outputs
40-70Hz line frequency range
