參數資料
| 型號： | 67-31B/SAC-BX1Y2B9Z5/2T |
| 廠商： | EVERLIGHT ELECTRONICS CO LTD |
| 元件分類： | LED |
| 英文描述： | SINGLE COLOR LED, REDDISH ORANGE |
| 封裝： | ROHS COMPLIANT, PLASTIC, LCC-3 |
| 文件頁數： | 4/10頁 |
| 文件大?。?/td> | 148K |
| 代理商： | 67-31B/SAC-BX1Y2B9Z5/2T |
EVERLIGHT ELECTRONICS CO.,LTD.
Everlight Electronics Co., Ltd.
http://www.everlight.com
Rev. 1
Page: 3 of 10
Device No. :
prepared date:05-Jan-2006
Prepared by: Venis Wu
67-31B/SAC-BX1Y2B9Z5/2T
Absolute Maximum Ratings (TA=25℃)
Parameter
Symbol
Rating
Unit
Reverse Voltage
VR
5
V
Forward Current
IF
70
mA
Operating Temperature
Topr
-40 ~ +85
℃
Storage Temperature
Tstg
-40 ~ +100
℃
Electrostatic Discharge(HBM)
ESD
2000
V
Power Dissipation
Pd
220
mW
Peak Forward Current
(Duty 1/10 @1KHz)
IFP
150
mA
Soldering Temperature
Tsol
Reflow Soldering : 260 ℃ for 10 sec.
Hand Soldering : 350 ℃ for 3 sec.
Electronic Optical Characteristics :
Parameter
Symbol
Min.
Typ.
Max.
Unit
Condition
Luminous Intensity
Iv
1800
-----
4500
mcd
IF=50mA
Viewing Angle
2θ1/2
-----
60
-----
deg
IF=50mA
Peak Wavelength
λP
-----
621
-----
nm
IF=50mA
Dominant Wavelength
λd
614
-----
622
nm
IF=50mA
Spectrum Radiation
Bandwidth
△λ
-----
18
-----
nm
IF=50mA
Forward Voltage
VF
2.15
-----
2.75
V
IF=50mA
Reverse Current
IR
-----
10
μA
VR=5V
Notes:
1.Tolerance of Luminous Intensity ±10%
2.Tolerance of Dominant Wavelength ±1nm
3.Tolerance of Forward Voltage ±0.1V
