Original Creation Date: 04/03/96
Last Update Date: 11/23/98
Last Major Revision Date: 11/06/98
MNLM7171AM-X REV 3A1
MICROCIRCUIT DATA SHEET
VERY HIGH SPEED, HIGH OUTPUT CURRENT, VOLTAGE FEEDBACK
AMPLIFIER
General Description
The LM7171 is a high speed voltage feedback amplifier that has the slewing characteristic
of a current feedback amplifier; yet it can be used in all traditional voltage feedback
amplifier configurations. The LM7171 is stable for gains as low as + 2 or -1. It provides
a very high slew rate at 2000V/uS (Minimum) and a wide gain-bandwidth product of 170MHz
(Minimum) while consuming only 6.5mA of supply current. It is ideal for video and high
speed signal processing applications such as HDSL and pulse amplifiers. With 100mA output
current, the LM7171 can be used for video distribution, as a transformer driver, or as a
laser diode driver.
Operation on +15V power supplies allows for large signal swings and provides greater
dynamic range and signal-to-noise ratio. The LM7171 is ideal for ADC/DAC systems. In
addition, the LM7171 is specified for +5V operation for portable applications.
The LM7171 is built on National's advanced VIP(TM)III(Vertically integrated PNP)
complementary bipolar process.
NS Part Numbers
LM7171AMJ-QML*
LM7171AMJ-QMLV**
LM7171AMW-QML***
LM7171AMW-QMLV****
LM7171AMWG-QML*****
LM7171AMWG-QMLV******
Industry Part Number
LM7171AM
Prime Die
LM7171
Controlling Document
See Features Page
Processing
MIL-STD-883, Method 5004
Quality Conformance Inspection
MIL-STD-883, Method 5005
Subgrp Description
Temp ( C)
o
1
Static tests at
+25
2
Static tests at
+125
3
Static tests at
-55
4
Dynamic tests at
+25
5
Dynamic tests at
+125
6
Dynamic tests at
-55
7
Functional tests at
+25
8A
Functional tests at
+125
8B
Functional tests at
-55
9
Switching tests at
+25
10
Switching tests at
+125
11
Switching tests at
-55
1
