Original Creation Date: 02/02/99
Last Update Date: 07/19/99
Last Major Revision Date: 02/02/99
MNCLC412A-X REV 0A0
MICROCIRCUIT DATA SHEET
Dual Wideband Video Op Amp
General Description
The Comlinear CLC412 combines a high-speed complementary bipolar process with Comlinear's
current-feedback topology to produce a very high-speed dual op amp.
The CLC412 provides a
250MHz small-signal bandwidth at a gain of +2V/V and a 1300V/us slew rate while consuming
only 50mW per amplifier from +5V supplies.
The CLC412 offers exceptional video performance with its 0.02% and 0.02 degrees
differential gain and phase errors for NTSC and PAL video signals while driving one back
terminated 75ohms load.
The CLC412 also offers a flat gain response of 0.1dB to 30MHz and
very low channel-to-channel crosstalk of -76dB at 10MHz.
Additionally, each amplifier can
deliver a 70mA continuous output current.
This level of performance makes the CLC412 an
ideal dual op amp for high-density broadcast-quality video systems.
The CLC412's two very well-matched amplifiers support a number of applications such as
differential line drivers and receivers.
In addition, the CLC412 is well suited for
Sallen Key active filters in applications such as anti-aliasing filters for high-speed A/D
converters.
Its low power requirement, low noise and low distortion also allow the CLC412
to serve portable RF applications such as IQ-channels.
NS Part Numbers
CLC412AE-QML**
CLC412AJ-QML*
Industry Part Number
CLC412A
Prime Die
UB1709A
Controlling Document
5962-9471901MPA*, M2A**
Processing
MIL-STD-883, Method 5004
Quality Conformance Inspection
MIL-STD-883, Method 5005
Subgrp Description
Temp ( C)
o
1
Static tests at
+25
2
Static tests at
+125
3
Static tests at
-55
4
Dynamic tests at
+25
5
Dynamic tests at
+125
6
Dynamic tests at
-55
7
Functional tests at
+25
8A
Functional tests at
+125
8B
Functional tests at
-55
9
Switching tests at
+25
10
Switching tests at
+125
11
Switching tests at
-55
1
