Electronic Components | Segments | Who We Are
Searc h
Home > Products > By Type > Single Fiber/Duplex Connectors > Product Feature Selector > Product Details
503135-1 Product Details
Product Photo
503135-1
T E I nternal N umber: 5 0 3 1 3 5 -1
Hybrid Adapters
Product Highlights:
l
Adapter
l
Connector Type = Duplex
l
Adapter Type = SC - FC
l
With Retention Clip
l
Plastic Housing Material
Quick Links
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
Additional Information:
l
Related Products:
l
Product Features (Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type = Adapter
l
Connector Type = Duplex
l
Adapter Type = SC - FC
Mechanical Attachment:
l
Flange = With
Termination Related Features:
l
Mode = Multimode, Singlemode
Body Related Features:
l
Retention Clip = With
l
Alignment Sleeve Material = Phosphor Bronze
Housing Related Features:
l
Housing Material = Plastic
l
Housing Color = Black
Industry Standards:
l
RoHS/ELV Compliance = Not reviewed for ELV/RoHS compliance
l
Lead Free Solder Processes = Not reviewed for lead free solder
process
Packaging Related Features:
l
Packaging Method = Box
l
Packaging Quantity = 10
Other:
l
Brand = AMP
