ICS502
LOCO PLL CLOCK MULTIPLIER
CLOCK MULTIPLIER
IDT / ICS LOCO PLL CLOCK MULTIPLIER
6
ICS502
REV L 092209
Package Outline and Package Dimensions (8-pin SOIC, 150 Mil. Narrow Body)
Package dimensions are kept current with JEDEC Publication No. 95
Ordering Information
*NOTE: EOL for non-green parts to occur on 5/13/10 per PDN U-09-01
Parts that are ordered with an “LF” suffix to the part number are the Pb-free configuration and are RoHS compliant.
While the information presented herein has been checked for both accuracy and reliability, Integrated Device Technology (IDT) assumes
no responsibility for either its use or for the infringement of any patents or other rights of third parties, which would result from its use. No
other circuits, patents, or licenses are implied. This product is intended for use in normal commercial applications. Any other applications
such as those requiring extended temperature range, high reliability, or other extraordinary environmental requirements are not
recommended without additional processing by IDT. IDT reserves the right to change any circuitry or specifications without notice. IDT
does not authorize or warrant any IDT product for use in life support devices or critical medical instruments.
Part / Order Number
Marking
Shipping Packaging
Package
Temperature
502M*
ICS502M
Tubes
8-pin SOIC
0 to +70
° C
502MT*
ICS502M
Tape and Reel
8-pin SOIC
0 to +70
° C
502MI*
ICS502I
Tubes
8-pin SOIC
-40 to +85
° C
502MIT*
ICS502I
Tape and Reel
8-pin SOIC
-40 to +85
° C
502MLF
Tubes
8-pin SOIC
0 to +70
° C
502MLFT
502MLF
Tape and Reel
8-pin SOIC
0 to +70
° C
502MILF
Tubes
8-pin SOIC
-40 to +85
° C
502MILFT
502MILF
Tape and Reel
8-pin SOIC
-40 to +85
° C
502-DWF
-
Die on uncut, probed wafers
0 to +70
° C
502-DPK
-
Tested die in waffle pack
0 to +70
° C
D
EH
c
h x 450
b
e
Q
A
Pin 1
Index
Area
Millimeters
Inches
Symbol
Min
Max
Min
Max
A
1.35
1.75
0.0532
0.0688
A1
1.10
0.25
0.0040
0.0098
B
0.33
0.51
0.013
0.020
C
0.19
0.25
0.0075
0.0098
D
4.80
5.00
.1890
.1968
E
3.80
4.00
0.1497
0.1574
e
1.27 Basic
0.050 Basic
H
5.80
6.20
0.2284
0.2440
h
0.25
0.50
0.010
0.020
L
0.40
1.27
0.016
0.050
a0
°
8
°
0
°
8
°
