4A004MH5
No.7427-1/5
Features
Inverter.
Enable to 25 voltage operation.
Low power-loss.
High speed operation.
Specifications
Absolute Maximum Ratings at Ta=25
°C
Parameter
Symbol
Conditions
Ratings
Unit
DC Supply Voltage
VDD
--0.3 to +25
V
Input Voltage
VIN
GND--0.3 to VDD+0.3
V
Output Voltage
VOUT
GND--0.3 to VDD+0.3
V
Input Current
IIN
±10
mA
Output Current
IOUT
±75
mA
Allowable Power Dissipation
PD
Mounted on a ceramic board (600mm2!0.8mm)
0.8
W
Storage Temperature
Tstg
--55 to +150
°C
Recommended Operating Conditions at Ta=25
°C
Parameter
Symbol
Conditions
Ratings
Unit
DC Supply Voltage
VDD
3 to +25
V
Input Voltage
VIN
0 to VDD
V
Output Voltage
VOUT
0 to VDD
V
Output Current
IOUT
VDD=25V
±50
mA
Input Rise And Fall Time
t / v
VDD<5V
≤100
ns / V
VDD≥5V
≤20
ns / V
Operating Temperature
Topr
--40 to +85
°C
Marking : XC
SANYO Electric Co.,Ltd. Semiconductor Company
TOKYO OFFICE Tokyo Bldg., 1-10, 1 Chome, Ueno, Taito-ku, TOKYO, 110-8534 JAPAN
Ordering number : ENN7427A
31005IP TS IM / D2503 TS IM TA-3912
Any and all SANYO products described or contained herein do not have specifications that can handle
applications that require extremely high levels of reliability, such as life-support systems, aircraft's
control systems, or other applications whose failure can be reasonably expected to result in serious
physical and/or material damage. Consult with your SANYO representative nearest you before using
any SANYO products described or contained herein in such applications.
SANYO assumes no responsibility for equipment failures that result from using products at values that
exceed, even momentarily, rated values (such as maximum ratings, operating condition ranges, or other
parameters) listed in products specifications of any and all SANYO products described or contained
herein.
4A004MH5
ExPD (Excellent Power Device)
Inverter
Truth Table
IN
OUT
LH
HL
H : High level voltage
L : Low level voltage
