- 您現在的位置：買賣IC網 > PDF目錄33214 > 2N1482 (MICROSEMI CORP-LAWRENCE) 1500 mA, 55 V, NPN, Si, SMALL SIGNAL TRANSISTOR, TO-5 PDF資料下載
參數資料
| 型號： | 2N1482 |
| 廠商： | MICROSEMI CORP-LAWRENCE |
| 元件分類： | 小信號晶體管 |
| 英文描述： | 1500 mA, 55 V, NPN, Si, SMALL SIGNAL TRANSISTOR, TO-5 |
| 封裝： | TO-5, 3 PIN |
| 文件頁數： | 2/2頁 |
| 文件大?。?/td> | 51K |
| 代理商： | 2N1482 |
2N1479, 2N1480, 2N1481, 2N1482 JAN SERIES
ELECTRICAL CHARACTERISTICS (con’t)
Characteristics
Symbol
Min.
Max.
Unit
ON CHARACTERISTICS
(1)
Forward-Current Transfer Ratio
IC = 200 mAdc, VCE = 4.0 Vdc
2N1479, 2N1480
2N1481, 2N1482
hFE
20
35
60
100
Collector-Emitter Saturation Voltage
IC = 200 mAdc, IB = 20 mAdc
2N1479, 2N1480
IC = 200 mAdc, IB = 10 mAdc
2N1481, 2N1482
VCE(sat)
0.75
Vdc
Base-Emitter Voltage
IC = 200 mAdc, VCE = 4.0 Vdc
VBE
1.5
Vdc
DYNAMIC CHARACTERISTICS
Forward Current Cutoff Frequency
IC = 5.0 mAdc, VCB = 28 Vdc
fab
800
kHz
SWITCHING CHARACTERISTICS
Total Switching Time
VCC = 12 Vdc; RC = 59 ; IB0 = IB2 = 8.5 mAdc; IB1= 20 mAdc
ton + toff
25
s
(1) Pulse Test: Pulse Width = 300
s, Duty Cycle ≤ 2.0%.
6 Lake Street, Lawrence, MA 01841
1-800-446-1158 / (978) 794-1666 / Fax: (978) 689-0803
120101
Page 2 of 2
