IGBT MODULE ( N series )
n
n Features
Square RBSOA
Low Saturation Voltage
Less Total Power Dissipation
Improved FWD Characteristic
Minimized Internal Stray Inductance
Overcurrent Limiting Function (
4~5 Times Rated Current)
n
n Applications
High Power Switching
A.C. Motor Controls
D.C. Motor Controls
Uninterruptible Power Supply
n
n Outline Drawing
n
n Maximum Ratings and Characteristics
Absolute Maximum Ratings ( T
c=25°C
)
Items
Symbols
Ratings
Units
Collector-Emitter Voltage
VCES
1200
V
Gate -Emitter Voltage
VGES
± 20
V
Continuous
IC
300
Collector
1ms
IC PULSE
600
Current
Continuous
-IC
300
1ms
-IC PULSE
600
Max. Power Dissipation
PC
2100
W
Operating Temperature
Tj
+150
°C
Storage Temperature
Tstg
-40
+125
°C
Isolation Voltage
A.C. 1min.
Vis
2500
V
Mounting *1
3.5
Terminals *2
4.5
Note: *1:Recommendable Value; 2.5
3.5 Nm (M5) or (M6)
*2:Recommendable Value; 3.5
4.5 Nm (M6)
Electrical Characteristics ( at T
j=25°C )
Items
Symbols
Test Conditions
Min.
Typ.
Max.
Units
Zero Gate Voltage Collector Current
ICES
VGE=0V VCE=1200V
3.0
mA
Gate-Emitter Leackage Current
IGES
VCE=0V VGE=
± 20V
45
A
Gate-Emitter Threshold Voltage
VGE(th)
VGE=20V IC=300mA
4.5
7.5
V
Collector-Emitter Saturation Voltage
VCE(sat)
VGE=15V IC=300A
3.3
V
Input capacitance
Cies
VGE=0V
48000
Output capacitance
Coes
VCE=10V
17400
pF
Reverse Transfer capacitance
Cres
f=1MHz
15480
tON
VCC=600V
1.2
tr
IC=300A
0.25
0.6
tOFF
VGE=
± 15V
1.5
tf
RG=2.7
0.35
0.5
Diode Forward On-Voltage
VF
IF=300A VGE=0V
3.0
V
Reverse Recovery Time
trr
IF=300A
350
ns
Thermal Characteristics
Items
Symbols
Test Conditions
Min.
Typ.
Max.
Units
Rth(j-c)
IGBT
0.06
Thermal Resistance
Rth(j-c)
Diode
0.15
°C/W
Rth(c-f)
With Thermal Compound
0.0167
n
n Equivalent Circuit
Screw Torque
Turn-on Time
Turn-off Time
s
A
Nm
