TECHNICAL DATA SHEET
MCX
RIGHT ANGLE JACK PCB
29K203-40ML5
Rosenberger Hochfrequenztechnik GmbH & Co. KG
Tel.: +49 8684 18-0
Page
P.O.Box 1260
D-84526 Tittmoning
Germany
Fax: +49 8684 18-499
www.rosenberger.de
email: info@rosenberger.de
2 / 2
RF_35/11.05/3.1
f(GHz)
Electrical data
Impedance
50
Ω
Frequency
DC to 6 GHz
Return loss
≥ 21 dB, DC to 6 GHz
Insertion loss
≤ 0.05 x
dB
Insulation resistance
≥ 1 GΩ
Center contact resistance
≤ 5.0 mΩ
Outer contact resistance
≤ 2.5 mΩ
Test voltage
750 V rms
Working voltage
335 V rms
Contact Current
1.5A DC max.
- VSWR in application depends decisive on PCB layout -
Mechanical data
Mating cycles
≥ 500
Center contact captivation
≥ 10 N
Engagement force
≤ 25 N
Disengagement force
8 N min. to 20 N max.
Environmental data
Temperature range
-55°C to +155°C
Thermal shock
CECC 22 220, Chapter 4.6.7
Vibration
CECC 22 220, Chapter 4.6.3
Corrosion
CECC 22 220, Chapter 4.6.10
Moisture resistance
CECC 22 220, Chapter 4.6.6
Max. soldering temperature
IEC 61760-1, +260°C for 10 sec.
2002/95/EC (RoHS)
compliant
Tooling
N/A
Suitable cables
N/A
Packing
Standard
100 pcs in blister; 1000 pcs tape & reel
Weight
1.1 g/pce
Draft
Date
Approved
Date
Rev.
Engineering change number
Name
Date
Inge Mühlauer
30/08/04
Hfling
25.11.10
f00
10-0880
M. Pemwieser
18/11/10
While the information has been carefully compiled to the best of our knowledge, nothing is intended as representation or warranty on
our part and no statement herein shall be construed as recommendation to infringe existing patents. In the effort to improve our
products, we reserve the right to make changes judged to be necessary.
