參數資料
型號： 1679508
元件分類： 多腳機架和面板連接器
英文描述： 7 CONTACT(S), FEMALE, MULTIWAY RACK AND PANEL CONN, CRIMP
封裝： ROHS COMPLIANT
文件頁數： 2/4頁
文件大?。?/td> 117K
代理商： 1679508
HC-D 7-EBUC-R Order No.: 1679508
http://eshop.phoenixcontact.de/phoenix/treeViewClick.do?UID=1679508
PHOENIX CONTACT GmbH & Co. KG
Page 2 / 4
http://www.phoenixcontact.com
Jul 12, 2009
Surge voltage category
III
Constructional and testing regulations
DIN VDE 0627/86
DIN VDE 0110/02.79
DIN VDE 0110-1/04.97
IEC 60664-1, DIN IEC 60512
IEC 60352
Number of positions
7
Insertion/withdrawal cycles
≥ 500
Design
D7
Connection in acc. with standard
IEC / EN
Conductor cross section
0.14 mm ... 1.5 mm
Connection cross section AWG
26 ... 16
Stripping length of the individual wire
3 mm +0,5 (0.14 mm2 ... 0.5 mm2)
3.5 mm +1,0 (0.5 mm2 ... 1.5 mm2)
Assembly instructions
Connectors may be operated only when there is no load/voltage.
Connection
The inserts may only be used in plastic housings at voltages >42
V, since it is not possible to connect the protective conductor and
the housing with each other.
Material data
Inflammability class acc. to UL 94
V0
Contact material
Copper alloy
Contact surface material
Ag (alternatively Au)
Contact carrier material
PA
Electrical characteristics
Rated voltage (III/3)
250 V
Rated surge voltage
4 kV
Rated current
10 A
相關PDF資料
PDF描述
1679511 15 CONTACT(S), FEMALE, MULTIWAY RACK AND PANEL CONN, CRIMP
1679524 25 CONTACT(S), FEMALE, MULTIWAY RACK AND PANEL CONN, CRIMP
1679537 40 CONTACT(S), FEMALE, MULTIWAY RACK AND PANEL CONN, CRIMP
1679546 64 CONTACT(S), FEMALE, MULTIWAY RACK AND PANEL CONN, CRIMP
1689637 9-9 CONTACT(S), PANEL MOUNT, FEMALE-FEMALE, RECTANGULAR ADAPTER
相關代理商/技術參數
參數描述
1679510000 制造商:Weidmuller 功能描述:SLZF 5.08/8 OG -EA - Bulk
1679511 功能描述:重負荷電源連接器 HC-D 15-EBUC-R RoHS:否 制造商:Hirose Connector 系列:PS2 產品類型:Connectors 位置/觸點數量: 端接類型:Crimp 觸點材料: 觸點電鍍:Gold 電壓額定值: 電流額定值:300 A 附件類型:
1679520000 制造商:Weidmuller 功能描述:SLZF 5.08/9 OG - Bulk
1679524 功能描述:重負荷電源連接器 HC-D 25-EBUC-R RoHS:否 制造商:Hirose Connector 系列:PS2 產品類型:Connectors 位置/觸點數量: 端接類型:Crimp 觸點材料: 觸點電鍍:Gold 電壓額定值: 電流額定值:300 A 附件類型:
167953-000 制造商:TE Connectivity 功能描述:TX40AB00-2412 制造商:TE Connectivity 功能描述:TX40AB00-2412 - Bulk
