HUBER+SUHNER SMC
102
TECHNICAL DATA
ELECTRICAL DATA
REQUIREMENTS
Impedance
50
Frequency range
DC ... 10 GHz
Dielectric withstanding voltage
(at sea level)
750 V rms, 50 Hz (depending on cable)
Working voltage (at sea level)
250 V rms for cables with 1 mm / 0.039 in. dielectric
335 V rms for cables with 2 mm / 0.078 in. dielectric
Insulation resistance
104 M
Contact resistance
- centre contact
-outer contact
5m
2.5 m
RF-leakage (measured at 1 GHz)
90 dB
MECHANICAL DATA
REQUIREMENTS
Coupling nut torque
- recommended
- proof torque
25 Ncm ... 35 Ncm / 2.2 in. lbs ... 3.1 in. lbs
71 Ncm / 6.2 in. lbs
Coupling nut retention force
150 N / 33.72 lbs
Contact captivation
10 N / 2.25 lbs
Cable retention force1)
see pages 28 – 34
Durability (matings)
500
1) Value considers maximum load of the cables without irreversible variations of specifications.
ENVIRONMENTAL DATA
TEST CONDITIONS
Temperature range
– 65 C ... + 165 C/ –85 F ... + 329 F
Climatic category
IEC
! 55 / 155 / 21
Thermal shock
MIL-STD-202, Method 107, Condition B
Moisture resistance
MIL-STD-202, Method 106
Corrosion
Saltspray test acc. to MIL-STD-202, Method 101, Condition B
Vibration
MIL-STD-202, Method 204, Condition D
